Composable APIs with Elixir pipes

Composable APIs with Elixir pipes

Our hero, climbing out of the mess that could be your library.

Taking lessons from Plug, Ecto, and Swoosh let’s examine how these libraries create composable and intuitive APIs like so:

# Plug
  |> put_resp_content_type("text/plain")
  |> send_resp(200, "Hello world")

# Ecto
  |> where(city: "Kraków")
  |> order_by(:temp_lo)
  |> limit(10)
  |> Repo.all

# Swoosh
  |> to({user.name, user.email})
  |> from({"Dr B Banner", "hulk.smash@example.com"})
  |> subject("Hello, Avengers!")
  |> html_body("<h1>Hello #{user.name}</h1>")
  |> text_body("Hello #{user.name}\n")


Because Elixir is immutable, libraries often feature some kind of model object (usually a struct) that gets passed around throughout the library. Examples include Plug.Conn and Ecto.Query.

These model objects are used in methods that look like this:

def do_something(model_object, param1, param2) do
  # Some computation
  %{ model_object | new_attribute: "new value"}

For example, the Plug.Conn model struct has the following fields:

defstruct adapter:         {Plug.Conn, nil},
            assigns:         %{},
            before_send:     [],
            body_params:     %Unfetched{aspect: :body_params},
            cookies:         %Unfetched{aspect: :cookies},
            halted:          false,
            host:            "www.example.com",
            method:          "GET",
            owner:           nil,
            params:          %Unfetched{aspect: :params},
            path_info:       [],
            port:            0,
            private:         %{},
            query_params:    %Unfetched{aspect: :query_params},
            query_string:    "",
            peer:            nil,
            remote_ip:       nil,
            req_cookies:     %Unfetched{aspect: :cookies},
            req_headers:     [],
            request_path:    "",
            resp_body:       nil,
            resp_cookies:    %{},
            resp_headers:    [{"cache-control", "max-age=0, private, must-revalidate"}],
            scheme:          :http,
            script_name:     [],
            secret_key_base: nil,
            state:           :unset,
            status:          nil

Wow! That’s a lot of fields! How on earth can a developer interact with an object of this complexity?

Naturally, we don’t expect anyone to be able (or want) to construct a valid payload of this caliber. Instead, as library authors we can provide a set of intuitive interfaces to interact with this gigantic struct.

By providing a set of methods to interact with the underlying struct, libraries ensure that each update made by the user obeys contracts and passes validations that need to be enforced.


Let’s look at one such method. Below is Plug’s put_resp_content_type:

def put_resp_content_type(conn, content_type, nil) when is_binary(content_type) do
  conn |> put_resp_header("content-type", content_type)

def put_resp_header(%Conn{adapter: adapter, resp_headers: headers} = conn, key, value) when
    is_binary(key) and is_binary(value) do
  validate_header_key!(adapter, key)
  %{conn | resp_headers: List.keystore(headers, key, 0, {key, value})}

For your reference, here’s how put_resp_content_type is used:

# Plug
  |> put_resp_content_type("text/plain")
  |> send_resp(200, "Hello world")

Here’s a simplified version of put_resp_content_type that’s a bit easier on the eyes:

def put_resp_content_type(conn, content_type) do
  %{ conn | resp_headers: List.keystore(headers, "content_type", 0, {"content_type", content_type})}

In essence, methods like put_resp_content_type and order_by does the following things:

  • First, it validates the user input,
  • transforms the user input to follow some desired structure or formatting,
  • inserts the transformed input into the struct, and finally
  • returns the new, updated struct

All of the above steps can occur without users needing to know the nitty-gritty implementation details beyond the method’s public signature.

In addition, by defining multiple methods you can create composable functions that is more idiomatic Elixir, due the prevalence of the pipe operator in the language.

# You'll see this pattern a lot in Elixir.
  |> where(city: "Kraków")
  |> order_by(:temp_lo)
  |> limit(10)
  |> Repo.all

In Closing

Many Elixir libraries such as Plug and Ecto provide functions that act as their public API, shielding users from the complexity underneath. This is a much better approach than having users build the model struct themselves (and inevitably screw up!)
